Technical Data

Compact Size – 1 Module (17,5 mm)
Phase sequence and phase loss
Phase loss detection even in the presence of regenerated voltages (up to 85%of nominal voltage)
Universal three phase supply 3×208-480 VAC
Din rail mounting
1 Exchange contact

Technical Data
Rated operational current up to 40 A DC
Output voltage from 3 to 120 VDC
Low control current
2500 V input-output insulation
CE certification

Technical Data
Input voltage led
Input voltage: 3-32 Vcc /4-32 Vcc, 90-280 Vac
Low control current
Rated operational current : 15/20/25/30/40/60 A
Zero crossing commutation
Output voltage up to 600Vac
Peak voltage up to 1200V
5000V input-output insulation
Integrated voltage transient protection with varistor
RoHS compliant
DIN rail mountable

Technical Data
Power supply 8-30V DC
Protection against polarity reversal
24V DC entry for relay on and maximum current setting
Setting button for maximum current (E-teach)
Alarm threshold 0.9*E-teach (-10%)
Current measurement from 2A up to 40A
Opensource exit for status signaling (8-30V DC)
Signaling led for starting, exit and error
Plug and push in terminal block for connection
Modbus RS4858 RTU (only for model ELC40-S)

Technical Data
Output = 8A-24 VDC (Ta=60°C)
5 mm width
High switching speed
Low control power
3,750 V input-output insulation

Technical Data
Faston connection
Input voltage led
Zero crossing Switch-on
Peak voltage up to 600V
3750Vrms input to output insulation
2500V input and outpu to case insulation
Built in RC and TVS protection
